Sat-Link WS6932 DVB-S DVB-S2 HD Satellite Meter With Spectrum Analyser

Professional HD Satellite Meter With Spectrum Analyzer For The Professional Satellite Engineer


Features
Frequency range: 950 - 2150 MHz (DVB-S)
16:9 color TFT LCD display with 4.5 "/ 11cm diagonal
Backlit keyboard (burn time 5,10,20 seconds or turn off)
Flashlight function
Built-in speaker
Angle calculation of azimuth, elevation and LNB tilt (after entering the coordination own data)
Spectrum-Analyzer
Constellation-diagram
Display the signal strength in percent and as a bar
Display of BER
Display of C / N
Display of signal level in dBµV
Unicable SCR measurement
DiSEqC 1.0 for DiSEqC switches or for multi-switches
DiSEqC 1.1 for control of 1-8 LNB
DiSEqC 1.2 motor control
Automatic Channel Search TV and radio
Reception and playback of DVB-S + S2 TV programs
Reception and playback of DVB-S + S2 radio programs
EPG (electronic program guide)
Format conversion 4:3 or 16:9
AV-Output: Using the adapter cable can be connected to the device to the TV and used as normal receiver
AV-Input:for connecting external devices such as Video-cameras.
Data transfer via USB memory stick:
- Firmware Updates
- Backup your own settings
- Restore the custom settings
- save Satellite-lists to edit on a PC
- Satellite lists again transferred to the device
- For viewing photos and playing MP3 files from USB memory stick
Built-in, easily replaceable 3000mA / h LION-Power Battery for 3-6 hours of operation
Technical data:

LNB/Tuner input: Connector: F type,feminin
Frequency range: 950 MHz - 2150 MHz
Signal lever: -65 dB/µV~-25 dB/µV
LNB supply : 13/18 V, max 350 mA
Mode: 2K, 8K
LNB Control: 22 KHz
DiSEqC : Ver. 1.0, 1.1, 1.2 + USALS

Demodulator: Front End: QPSK
Symbolrate: 2 Mbps~45 Mbps
SCPC and MCPC: Yes
Spectrum Analyzer: YES

System resource: Processor: 32bit processor (133MHz)
SDRAM: 16 MB (64Mhz)
FLASH: 8 MB
EEPROM: 16*16 MB (DDR1)

Video decoder: MPEG 2 : Main Proflie@Main Level
Data Rate: up to 15 Mbits/s
Resolution: 720 x 576 (PAL), 720 x 480 (NTSC)
Video Format: PAL / NTSC / SECAM

MPEG Audio: MPEG 1 layer 1&2
Typ: Mono
Sampling: 32, 44.1 and 48 KHz


Serial data interface: Connector: USB Type

Power supply: Li-oN Batteriy: 3000mA/h
Supply Voltage: 12,6 Volt
Charger: 90 - 240 V / AC - 14,5 V / DC 1 A

Physical Specification: Size: 9,5 x 15,5 x 4,5 cm
Wight: 0,5 Kg
Package including:
1X WS-6932
1X yellow Protective rubber cover
1X large nylon carry bag with shoulder strap
1X 220V charging adapter
1X 12V car charger
1X A / V Cable Adapter 3.5 jack to 3x RCA jack
1X User manual OF CD
